多层胶合光学镜片(Multi-layer bonding products)
多层胶合光学镜片胶合可以将两个或多个光学元件胶合在一起，形成一个更大的、更复杂的光学元件。这种组合可以提高光学元件的性能，例如增加光学元件的焦距、减小像差、提高分辨率等。此外，镜片胶合还可以将不同材料的光学元件胶合在一起，形成复合材料，从而减少材料的使用量和制造成本，减少光学元件之间的接口和连接，减少光学元件的故障率和维修成本，提高光学元件的机械强度和耐热性，从而减少光学元件的损坏和提高有效性。
Multi layer bonding optical lenses can bond two or more optical elements together to form a larger and more complex optical component. This combination can improve the performance of optical components, such as increasing the focal length of optical components, reducing aberration, and improving resolution. In addition, lens bonding can also bond optical components of different materials together to form composite materials, thereby reducing material usage and manufacturing costs, minimizing interfaces and connections between optical components, reducing the failure rate and maintenance costs of optical components, improving the mechanical strength and heat resistance of optical components, thereby reducing damage to optical components andimproving effectiveness.
|
材料 Material |
各种光学玻璃，石英，晶体等 Various optical glasses, quartz, crystals, etc |
|
规格尺寸 Specifications |
Dia5.0~Dia80 5*5~80*80 |
|
5点测量平行度 Parallelism |
≤0.01mm（或根据客户要求制作) Can be inspected according to customer drawing requirements |
|
公差 Tolerance |
外形(shape):±0.05mm&+0/-0.10mm或其它(or other) 厚度(Thickness):根据客户要求(胶合层数不同，厚度公差有差异) According to customer requirements (different bonding layers and thickness tolerances) |
|
胶合胶水 glue |
日本进口专用光学镜片胶合胶水，不易解胶，不易开胶 Special optical lens adhesive imported from Japan，Not easy to remove glue, not easy to open glue |
|
胶合层数 layers |
根据客户要求订制（一般2~7层不等) Customized according to customer requirements (generally ranging from 2 to 7 layers) |
|
表面光洁度 Scratch Dig |
60/40，40/20，20/10，0/4 可根据客户要求制作（ustomized according to customer requirements ）。 |
我公司常规光学胶合件(Our company's standard optical bonding parts):
|
4 layer quartz crystal+quartz crystal+Blue Glass+quartz crystal (Optical Low Pass Filter,OLPF) |
2 layer Colored Glass+Colored Glass (pandpsss Filter) |
|
3 layer bonding(quartz+0.145 D263+quartz) edge polishing Coating reflector mirror |
CCD&CMOS bonding IR-Cut Filter&OLPF
|
